IP Phones

C200

128×48-dot matrix display with backlight, 2 SIP accounts, HD voice, PoE support, 4 soft keys,

C200Product model
2 linesSIP line
5V / 1APower input

Product details

The new C200 color-screen IP phone is a high-end business desktop phone, equipped with an intelligent LCD to increase user productivity at a cost-effective price.

The C200 inherits all the features of business phones, such as HD voice on the handset, headset and full-duplex speakerphone modes, PoE, Fast/Gigabit Ethernet, QoS, secure transmission, auto-provisioning, and more.

To help users who wish to read every product detail, this user manual is provided as a reference guide. However, the document may not be up to date with recently released software; please download the latest user manual from the website or contact support if you have any questions about the C200.

Key features

General

HD microphone/speaker (handset/listening, frequency response 0~7 kHz)

Handset (HS) / listening (HF) / headset (HP) mode (EHS support for Plantronics headsets)

POE

Desktop/wall installation

Call features

Make/answer/reject calls

Mute/unmute

Call hold/resume

Call waiting

Intercom

Caller ID display

Call forwarding (Always/Busy/No Answer)

Blind/attended call transfer

Call parking/retrieval

Redial/automatic redial

DND (per line / per phone)

Auto answer (per line / per phone)

3-way conference

Emergency line

Phone features

Phonebook (500 entries)

Cloud phonebook

Call log (incoming/outgoing/missed)

Blacklist, whitelist

Message waiting indication (VMWI)

Programmable soft keys

Network time synchronization

Action URL / active URI

Network

Network access control:802.1x

IP configuration: Static/ DHCP/ PPPoE

VPN: L2TP/OpenVPN

VLAN

QoS

Certification

CE

Audio

Codec: G.711a/u, G.723.1, G.722, G.726-32, G.729AB

Full-duplex acoustic echo cancellation (AEC)

Voice activity detection (VAD)

Comfort noise generation (CNG)

Background noise estimation (BNE)

Noise reduction (NR)

Packet loss concealment (PLC)

Dynamic adaptive jitter buffer up to 300 ms

DTMF: In-band, Out-of-band —DTMF -Relay(RFC2833) / SIP INFO

Protocols

SIP2.0 over UDP/TCP/TLS

RTP/RTCP/SRTP

STUN

DHCP

PPPoE

802.1x

L2TP (Basic Unencrypted)

OpenVPN

SNTP

FTP/TFTP

HTTP/HTTPS

TR069

RFCs

354/1321/1350/1769/1889/1890/ 2131/2132/2616/2617/2661/2833/ 2976/3261/3262/3263/3264/3265/ 3268/3311/3489/3711/4346/4566/ 5630/586

Deployment & Maintenance

Auto-provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP PNP/TR069

Web management portal

Web packet capture

Configuration import/export

Phonebook import/export

Firmware update

syslog

Specifications

C200 — Specifications
Specification	Value
Product model	C200
SIP line	2 lines
Installation	Bureau/mur
Screen	128 x 48 dots with backlight
Key Pad	31 keys, including: / 12 standard numeric keys; / 4 soft keys; / 4 navigation keys + 1 OK key; / 1 listening key; / 2 volume control keys, Up/Down; / 6 function keys /
Protocols	SIP 2.0 over UDP/TCP/TLS, RTP/RTCP/SRTP, STUN, DHCP, PPPoE, 802.1x, L2TP (Basic Unencrypted), OpenVPN, SNTP, FTP/TFTP, HTTP/HTTPS, TR069
Codec	G.711a/u, G.723.1, G.722, G726-32, G.729AB
Network interface	1 * 10/100 M (802.3af Class 1 POE); PC*1 (bridge to Ethernet)
IP service	Static IP, DHCP, VPN, PPPoE, Bridge
DTMF	In-band, Out-of-band- DTMF (RFC2833) / SIP INFO
Power supply	PoE / Power adapter
Power input	5V / 1A
Power consumption	Idle: 1.3W, Peak : 4.3W
Operating environment	Temperature: 0~40℃；Humidity: 10~65%
HD speaker listening	1 ( 0~7KHz)
HD microphone listening	1 ( 0~7KHz)
HD RJ9 handset	1 (with standard RJ9 handset cord)
1.5 m CAT5 cable	1
Phonebook	500 entries
Call log	600 entries
Cloud phonebook	XML/LDAP
Packaging dimensions	260x255x62mm (L x W x H)
