OpenVox UC300 IPPBX

Whether you are an SME looking for a cost-effective, scalable phone system or a SOHO requiring an advanced unified communications system, the OpenVox UC300 Series will be your first choice. With two distinct offerings, UC300-A11EM1/UC300-A20EM1 and UC300-A14EM1, OpenVox offers a complete product range designed to meet your communication needs.

Made of aluminum, the UC300 IP PBX Series places great emphasis on protection from dust and insects with a closed, fanless design. The UC300 is incredibly easy to configure with a basic setup, and you can also freely install your own Linux-based software.

The UC300 Series supports analog FXO/FXS ports with up to 60 concurrent calls on a single device. It is developed with a wide selection of codecs and signaling protocols, including G711 (alaw/ulaw), G722, OPUS, AMR-NB/WB, SILK, G723.1 G726, G729, GSM, ADPCM, iLBC, H263, H263P, H264, VP8. Making full use of the open source platform, the UC300 Series supports standard SIP trunks, IAX2 trunks, analog PSTN trunks, and analog station trunks. In addition, users can conveniently add ports to expand the system.

Technical specifications

Up to 300 registered extensions

150 concurrent calls

Recording: 86 000 min (.gsm); 9 500 min (.wav)

Voicemail: 86 000 min (.gsm); 9 500 min (.wav)

Network interface: 1×10/100M LAN port

USB port: 1×USB 2.0 for external storage or disaster recovery system

External storage: 1×SD slot, supports up to 128 G

Telephone interfaces: FXS/FXO interface, optional

Storage: 16 GB onboard Flash

RAM: DDR3 1 GB

1 MIC interface: audio input

1 SPK interface: audio output

Power consumption: 12 V/1,3 A, 16 W maximum

Failover function (not supported with the 2 FXO model)

Operating temperature: 0 °C to 50 °C

Storage temperature: -20 °C to 65 °C

Dimensions: 130 × 130 × 40 mm

Weight: 530 g

Certifications

RoHS compliant

Certificates: CE

Security

Firewall

Audit

Weak keys

Software & Platform:

Linux OS
